PLANET POE-151S

จำนวนครั้งที่เปิดดูสินค้า : 10236 | ความคิดเห็น: 0

เพิ่มเมื่อ: 2013-06-20 10:54:01.0

แก้ไขล่าสุด: 2021-10-05 17:21:47.0

เบอร์โทรติดต่อ: 062-5193997 , 02-4582949

อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
POE-151S IEEE 802.3af Power Over Ethernet Splitter (5V&12V) (สินค้ารับประกัน 3 ปี)

990.00 บาท

Planet POE-151S

POE-151S IEEE 802.3af Power Over Ethernet Splitter (5V&12V)

- Complies with IEEE 802.3af Power over Ethernet, IEEE 802.3/802.3u 10/100Base-TX Ethernet standard

- Splits the 48V DC power over RJ-45 Ethernet cable into different DC output

- LED indicators for power input indication

- Data and power transmission distance up to 100 meters

- Adjustable two different output voltage options (5V/2A, 12V/1A) to fit various devices

- Auto-Detect of IEEE 802.3af PoE equipment, protects devices from being damaged by incorrect installation

- Works with EIA568, category 5,4-pair cables for 10Base-T or 100Base-TX

Hardware Specification
Hardware Version	Version 3
Standard	IEEE 802.3af Power over Ethernet IEEE 802.3 10Base-T IEEE 802.3u, 10/100Base-TX
Ethernet Connector	2 x RJ-45 (1 for Data + DC in, 1 for Data out)
Data Rate	10/100Mbps (vary on Ethernet device attached)
DIP Switch	Adjustable output DC voltage: - 5VDC (Default) - 12VDC
Number of Device can be powered	1
Ethernet Cable	TIA / EIA-568, Category 5/5e cable
LED indicator	1 x PoE ready / in-use
Dimension (W x D x H)	73 x 55 x 24 mm
Emission	FCC Class B, CE mark
Environmental
Operating	Temperature: 0~50 Degree C Relative Humidity: 5~90%
Storage	Temperature: -20~70 Degree C Relative Humidity: 5~90%
