TP-LINK TL-SL2218 16-Port 10/100Mbps + 2 Gigabit RJ45 Ports and 2 Combo SFP Slots

 เพิ่มเมื่อ: 2017-03-08 14:02:08.0
 แก้ไขล่าสุด: 2019-05-06 17:11:19.0
 เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
 อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
16-Port 10/100Mbps + 2-Port Gigabit Smart Switch, 16 10/100Mbps RJ45 ports, 2 Gigabit RJ45 Ports and 2 Combo SFP Slots(สินค้ารับประกัน ตลอดอายุการใช้งาน)
4990.00 บาท

ส่งอีเมลล์ให้เพื่อน

TP-LINK TL-SL2218

TL-SL2218 16-Port 10/100Mbps + 2-Port Gigabit Smart Switch, 16 10/100Mbps RJ45 ports, 2 Gigabit RJ45 Ports and 2 Combo SFP Slots

 - 16 10/100Mbps RJ45 Ports, 2 10/100/1000Mbps RJ45 Ports and 2 Combo Gigabit SFP Slots.

- Integrated security strategy including 802.1Q VLAN, Port Security and Storm control help protect

  LAN area investment.

- Quality of Service (QoS, L2 to L4) traffic management capabilities to move your data smoother

  and faster.

- L2/L3/L4 QoS and IGMP snooping optimize voice and video application.

- WEB managed modes, SNMP, RMON bring abundant management features.

 Standards and Protocols

 - IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z,IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,

  IEEE 802.1w, IEEE 802.1q, IEEE 802.1p

 Interface

- 16 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

- 2 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)- 2 Combo Gigabit SFP Slots

 Network Media

- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

- 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)

- 100BASE-FX:MMF,SMF

- 1000BASE-X: MMF, SMF

Dimensions (W X D X H)

 - 17.3*7.1*1.7 in.(440*180*44 mm)

Fan Quantity

- Fanless

Power Supply

- 100~240VAC, 50/60Hz

Performance

- Bandwidth/Backplane 7.2Gbps

- MAC Address Table 8k

- Packet Buffer Memory 5.4Mpps

Quality of Service

- Support 802.1p CoS/DSCP priority

- Support 4 priority queues

- Queue scheduling: SP, WRR, SP+WRR

- Port/Flow-based Rate Limiting

 L2 Features

- IGMP Snooping V1/V2/V3

- LAG(Up to 6 aggregation groups,

- containing 4 ports per group)

- Spanning Tree STP/RSTP/MSTP

- BPDU Filtering/Guard

- TC/Root Protect

- Loop back detection

- 802.3x Flow Control

 VLAN

- Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)

 Security

 - Port Security

- Broadcast/Multicast/Unknown-unicast Storm Control

Management

 - Web-based GUI

- SNMP v1/v2c/v3,compatible with public MIBs and

- TP-LINK private MIBs

- RMON (1, 2, 3, 9 groups)

- CPU Monitoring

- Port Mirroring

- Firmware Upgrade: Web

- System Diagnose: VCT

- SYSLOG & Public MIBS

Certification

- CE, FCC, RoHS


Package Contents

 - TP-LINK TL-SL2218 Switch

- Power Cord;

- Installation Guide;

- Resource CD;

- Rackmount Kit;

- Rubber Feet

System Requirements

- Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, GetWare, UNIX or Linux.

Environment

 - Operating Temperature: 0C~40C (32F~104F);

- Storage Temperature: -40C~70C (-40F~158F)

- Operating Humidity: 10%~90% non-condensing

- Storage Humidity: 5%~90% non-condensing
