D-LINK DGS-1210-26
DGS-1210-26 Web Smart Switch with 24 10/100/1000Base-T ports and 2 1000Base-X SFP ports,24 10/100/1000Base-T, Full/half duplex for 10/100 Mbps speeds, 100 to 240 V AC 50/60 Hz, internal universal power supply
- 24 port Gigabit switch, with two (2) additional 1GbE SFP ports.
- Power-saving D-Link Green technology.
- Solid security with 802.1X authentication and IP/MAC based Access Control Lists (ACL).
- Malicious traffic and performance degradation prevention with D-Link Safeguard Engine.
- Auto Voice VLAN for the automatic prioritisation of digital voice traffic.
- Quality of service (QoS) and bandwidth control (down to 16 kbps).
- High Reliability with Loopback Detection (LBD) and cable diagnostics.
- Simple Web based management.
Interfaces
- 24 x 10/100/1000BASE-T
- 2 x 100/1000 Mbps SFP ports
Port Standards
- IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
- IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
- IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
- IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic
- IEEE 802.3az Energy Efficient Ethernet (EEE)
- IEEE 802.3x Flow Control
Network Cables
- UTP Cat. 5, Cat. 5e (100 m max.)
Duplex Mode
- Full/Half-duplex for 10/100 Mbps
- Full-duplex for 1000 Mbps
Media Interface Exchange
- Auto MDI/MDIX adjustment for all twisted-pair ports
Switching Capacity
- 52 Gbps
Transmission Method
- Store-and-forward
MAC Address Table
- 8K entries
Static MAC Addresses
- 256 entries
Maximum 64 Byte Packet Forwarding Rate
- 38.7 Mpps
Packet Buffer Memory
- 4.1 Mbits
CPU Memory
- DDR3 128 MB
Flash Memory
- 32 MB
Power Input
- 100 to 240 V AC 50/60 Hz internal universal power supply
Maximum Power Consumption
- 15.22 W/100 V
- 15.11 W/240 V
