| D-LINK DGS-1100-08PV2 8-port Gigabit Smart Managed PoE (64W) Switch, Power budget 78Watt
D-LINK DGS-1100-08PV2 8-port Gigabit Smart Managed PoE (64W) Switch, Power budget 78Watt
เพิ่มเมื่อ: 2019-11-21 13:02:49.0
แก้ไขล่าสุด: 2024-02-15 10:58:45.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comDGS-1100-08PV2 8-port Gigabit Smart Managed PoE (64W) Switch(Port 1-8 Up to 30W per port), Power budget 78Watt (สินค้ารับประกันตลอดอายุการใช้งาน)
D-LINK DGS-1100-08PV2
DGS-1100-08PV2 8-port Gigabit Smart Managed PoE (64W) Switch(Port 1-8 Up to 30W per port), Power budget 78Watt
• 8 x 10/100/1000BASE-T PoE ports
• Supports IEEE 802.3at PoE
• 64W PoE power budget
• Compact design for convenient placement
• Fanless design for silent operation
• Innovative D-Link Green energy saving features
• Complete web interface for comprehensive switch management
Hardware Version
- A1
Size
- Desktop
Number of Ports
- 8 10/100/1000 Mbps PoE
Port Functions
- Auto MDI/MDIX
- IEEE 802.3x Flow Control supports fullduplex mode
- IEEE 802.3az compliant
Switching Capacity
- 16 Gbps
Maximum Forwarding Rate
- 11.9 Mpps
MAC Address Table Size
- 8K Entries
Packet Buffer
- 2 Mbits
Flash Memory
- 2 Mbytes
PoE Standard
- IEEE 802.3af
PoE Capable Ports
- Ports 1 to 8 (15.4 watts max. per PoE port)
PoE Power Budget
- 64 watts
Standby Mode
- 2.0 watts
Maximum Power Consumption
- 78.8 watts (PoE on)
- 5.2 watts (PoE off)
Power Input
- 100 to 240 V AC
- 50 to 60 Hz External Power Adapter
MTBF
- 708,219 hours
Acoustics
- 0 dB(A)
Heat Dissipation
- 268.87 BTU/hr
Weight
- 0.706 kg (1.553 pounds)
Dimensions
- 190 x 120 x 38 mm (7.4 x 4.7 x 1.1 inches)
Ventilation
- Fanless
- Operating Temperature
- 0 to 40 °C (32 to 104 °F)
Storage Temperature
- -10 to 70 °C (14 to 158 °F)
Operating Humidity
- 10% to 95% non-condensing
Storage Humidity
- 5% to 95% non-condensing
EMI
- FCC Class A, CE Class A, VCCI Class A, C-Tick
Safety
- cUL, CE LVD
