TP-LINK TL-SG1016PE 16-Port Gigabit Easy Smart PoE Switch with 8-Port PoE
เพิ่มเมื่อ: 2017-08-16 14:12:49.0
แก้ไขล่าสุด: 2025-02-26 16:36:55.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comSWITCH (สวิตซ์) TP-LINK TL-SG1016PE 16-Port Gigabit Desktop/Rackmount PoE+ Easy Smart Switch, 16 Gigabit RJ45 ports including 8 PoE+ ports, 110W PoE Power supply, PoE Managment, MTU/Port/Tag-based VLAN, QoS, IGMP Snooping, Steel case
TP-LINK TL-SG1016PE
SWITCH (สวิตซ์) TP-LINK TL-SG1016PE 16-Port Gigabit Desktop/Rackmount PoE+ Easy Smart Switch, 16 Gigabit RJ45 ports including 8 PoE+ ports, 110W PoE Power supply, PoE Managment, MTU/Port/Tag-based VLAN, QoS, IGMP Snooping, Steel case
- 16× 10/100/1000Mbps RJ45 ports
- Equipped with 8× PoE+ supported ports to transfer data and power over a single cable
- With a total PoE power budget of 150 W,* up to 30 W per port
- Works with IEEE 802.3af/at compliant devices
- Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto recovery
- Simple network set-up on top of plug-and-play connectivity
- Web-based user interface and management utility simplify configuration
- Silent Operation
Standards and Protocols : IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface :
16× 10/100/1000 Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media :
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity : Fanless
Physical Security Lock : Yes
PoE Ports (RJ45) :
Standard: 802.3 af/at compliant
PoE Ports: Port 1 to Port 8
PoE Power Budget: 150 W
Dimensions ( W x D x H ) : 11.6×7.1×1.7 in (294×180×44 mm)
Mounting Rack Mountable/ Desktop
Max Power Consumption :
13.07 W (220 V/50 Hz with no PD connected)
173.88 W (220 V/50 Hz with 150 W PD connected)
Max Heat Dissipation :
44.438 BTU/h (220 V/50 Hz with no PD connected)
591.192 BTU/h (220 V/50 Hz with 150 W PD connected)
Switching Capacity : 32 Gbps
Packet Forwarding Rate : 23.8 Mbps
MAC Address Table : 8K
Packet Buffer Memory : 4.1 Mbit
Jumbo Frame : 10 KB
Quality of Service :
Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
L2 Features :
IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
VLAN :
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
PoE :
PoE Management
Extend Mode
PoE Auto Recovery
Management :
Web-based GUI
Easy Smart Configuration Utility
Transmission Method : Store-And-Forward
Package Contents :
TL-SG1016PE
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet
