| WiFi Ceiling Access point
| TP-LINK EAP772 BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
TP-LINK EAP772 BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
เพิ่มเมื่อ: 2025-01-22 12:36:22.0
แก้ไขล่าสุด: 2025-01-22 12:36:35.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comWi-Fi 7 Access Point TP-LINK EAP772 BE9300 Ceiling Mount Tri-Band Access Point, 1×2.5G RJ45 Port, 574Mbps at 2.4 GHz + 2880 Mbps at 5 GHz+ 5760 Mbps at 6 GHz
TP-LINK EAP772
Wi-Fi 7 Access Point TP-LINK EAP772 BE9300 Ceiling Mount Tri-Band Access Point, 1×2.5G RJ45 Port, 574Mbps at 2.4 GHz + 2880 Mbps at 5 GHz+ 5760 Mbps at 6 GHz
- BE9300 Tri-Band Wi-Fi 7 (5765 Mbps on 6 GHz + 2882 Mbps on 5 GHz + 688 Mbps on 2.4 GHz).
- A clear 6 GHz band brings cleaner and wider band resources.
- 1× 2.5G Port unlocks the full potential of Wi-Fi 7.
- 320 MHz bandwidth enables many more simultaneous transmissions.
- Multi-Link Operation and Multi-RUs ensure the high performance of your network.
- Advanced Functions: Centralized management, mesh, and AI roaming.
Interface : 1× 2.5G Ethernet Port
Button : Reset
Power Supply : 802.3at PoE or 12V/2.5A DC
Power Consumption :
• 24.05 W (For PoE);
• 20.92 W (For DC)
Dimensions ( W x D x H ) : 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
Antenna Type :
• 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
• 6 GHz: 2× 5.0 dBi
Bluetooth :
1 × 4.0 dBi, Bluetooth 5.2
*Firmware update may be required.
Mounting : Ceiling / Wall Mounting (Kits Included)
Coverage : 140㎡(1500 ft²)§
Wireless Client Capacity : 380+**
Wireless Standards : IEEE 802.11 a/b/g/n/ac/ax/be
Frequency : 6 GHz, 5 GHz, and 2.4 GHz
Signal Rate : 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz) + 5765 Mbps (6 GHz)†
Wireless Security :
• Captive Portal Authentication△
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power :
< 20 dBm (2.4 GHz, EIRP)
< 23 dBm (5 GHz, band 1&band 2, EIRP)
< 28 dBm (5 GHz, band 3, EIRP)
< 23dBm (6 GHz, EIRP)
Package Contents :
• EAP772
• Installation Guide
• Ceiling/Wall Mounting Kit
Note: Power Adapter is NOT included.
