PLANET FGSD-910P 8-Port 10/100Mbps 802.3af PoE + 1-Port 10/100/1000Mbps Desktop Unmanaged Switch

จำนวนครั้งที่เปิดดูสินค้า : 7486 | ความคิดเห็น: 0

PLANET FGSD-910P 8-Port 10/100Mbps 802.3af PoE + 1-Port 10/100/1000Mbps Desktop Unmanaged Switch

เพิ่มเมื่อ: 2014-11-30 20:33:06.0

แก้ไขล่าสุด: 2019-04-29 14:47:54.0

เบอร์โทรติดต่อ: 062-5193997 , 02-4582949

อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
FGSD-910P 13" 8-Port 10/100Mbps 802.3af PoE switch with 1-Port Gigabit Uplink (130w.) (สินค้ารับประกัน 3 ปี)

5900.00 บาท

PLANET FGSD-910P

FGSD-910P 13" 8-Port 10/100Mbps 802.3af PoE switch with 1-Port Gigabit Uplink (130w.)

Centralized Power Distribution for Ethernet Networking
The FGSD-910P, a new member in PLANET 802.3af PoE Fast Ethernet Switch family, is an 8-Port 10/100Mbps 802.3af Power over Ethernet + 1-Gigabit Port Switch with a total of 120 watts of PoE budget, which is an ideal solution to fulfilling the demand of sufficient PoE power for network applications with Fast Ethernet speed transmission. The eight 802.3af PoE ports provide PoE power injector function which is able to drive 8 IEEE 802.3af compliant powered devices. The FGSD-910P also provides a simple, cost-effective and non-blocking wire-speed performance. It comes with a 12-inch metal compact housing, suitable for desktop deployment in SOHO office or department network application.

Ideal Solution for Securing IP Surveillance Infrastructure
Particularly designed for the growing popular IP Surveillance applications, the FGSD-910P 802.3af PoE Switch is positioned as a Surveillance Switch for quick and easy PoE IP camera deployment with power feeding. The FGSD-910P provides 802.3af PoE functions along with 8 10/100Base-TX ports featuring 15.4-watt 802.3af PoE in RJ-45 copper interfaces and 1 extra Gigabit TP interface supporting high speed transmission of surveillance images and videos.

Perfectly Integrated Solution for PoE IP Camera and NVR System
Different from the general IT industrial PoE Switch which usually comes with 12 or 24 PoE ports, the FGSD-910P provides eight 802.3af PoE ports for catering to small scale of IP Surveillance networks at a lower total cost. The FGSD-910P comes with high performance switch architecture and 120-watt PoE power budget. The recorded video files from 8 PoE IP Cameras can be powered by the FGSD-910P and saved in the 8-channel NVR system or surveillance software to perform comprehensive security monitoring. For instance, one FGSD-910P can be combined with one 8-Channel NVR and 8 PoE IP cameras as a kit for the administrators to centrally and efficiently manage the surveillance system in the local LAN and the remote site via Internet.

Applications

802.3af PoE IP Surveillance in Public Transportation
Providing up to eight 802.3af PoE, in-line power interfaces and 1 Gigabit TP interface, the FGSD-910P can easily build a power centrally controlled IP Camera system for the enterprises. It can work with 8-Channel NVR and surveillance software to perform comprehensive security monitoring. For instance, one FGSD-910P can be combined with one 8-Channel NVR; that is, each of its PoE port can be inked to a specific 802.3af PoE IP camera for the administrators to centrally and efficiently manage the surveillance system in one site. The 1 Gigabit TP interface in the FGSD-910P also provides Gigabit TP connection for uplink to public server groups.

IP Office Department / Workgroup PoE Switch
With the business office expansion, the additional telephones required could be installed in less cost via the implementation of PoE IP Telephony system than that of the traditional circuit wiring telephony system. The FGSD-910P PoE Ethernet Switch helps enterprises to create an integrated data, voice, and powered network. The IEEE 802.3af compliant IP Phones can be installed without the need of an additional power cable because the power can be provided via the standard Ethernet cable from the connected FGSD-910P.

The Wireless AP group, PoE IP Phones and Analog Telephony Adapter work perfectly with the FGSD-910P which injects power through the Ethernet cables. With the FGSD-910P, IP Telephony deployment becomes more reliable and cost effective, which helps enterprises save tremendous cost when upgrading from the traditional telephony system to IP Telephony communications infrastructure.

Features

RJ-45 Interface

8-Port 10/100Mbps Fast Ethernet Switch
8-Port supports 48V DC power to PoE Powered Device
1-Port 10/100/1000Mbps Gigabit Ethernet Switch

Power over Ethernet

Complies with IEEE 802.3af Power over Ethernet End-Span PSE
Up to 8 IEEE 802.3af devices powered
Supports PoE Power up to 15.4 watts for each PoE port
120-watt PoE budget
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m

Switching

Hardware based 10/100Mbps auto-negotiation and auto MDI/MDI-X (Port 1 to Port 8)
Hardware based 10/100/1000Mbps auto-negotiation and Auto MDI/MDI-X (Port 9)
Flow control for full duplex operation and back pressure for half duplex operation
Integrates address look-up engine, supporting 4K absolute MAC addresses
Automatic address learning and address aging

Hardware

12-inch desktop size, 1U height
LED indicators for system power, per port PoE ready and PoE activity, speed, Link / Act
1 silent FAN to provide stable and efficient power performance
